Premium Mobile 4-inch Wide Standard
This 4-inch mobile printer is optimized for high-volume label printing and also prints receipts and linerless media. The ZQ630 Plus features fast connections with Wi-Fi 6 (802.11ax) and Bluetooth 5.3 dual radio, best-in-class security, large color display, patented battery and battery management technologies and instant wake-up feature. The ZQ630 Plus can be mounted to a forklift for easy access while moving throughout the warehouse. Wi-Fi 5 (802.11ac) and Bluetooth 4.2 option also available.
In the Box
Key Features
Commonly Used For
| Parameter / Feature | Specification Details |
| PHYSICAL - Dimensions | ZQ610 Plus: 6.73 x 3.6 x 2.85 in. (170.9 x 91.4 x 72.4 mm) | ZQ620 Plus: 6.84 x 4.64 x 3.03 in. (173.7 x 117.9 x 76.9 mm) | ZQ630 Plus: 7.35 x 6.5 x 3.25 in. (186.7 x 165.1 x 82.5 mm) (Note: Extended Capacity battery adds 0.6 in. / 16 mm to height) |
| PHYSICAL - Weight with Battery | ZQ610 Plus: 1.33 lbs (0.6 kg) | ZQ620 Plus: 1.6 lbs (0.73 kg) | ZQ630 Plus: 2.45 lbs (1.1 kg) |
| PRINTER SPEC - Operating System | Link-OS™ |
| PRINTER SPEC - Resolution | 203 dpi (8 dots per mm) |
| PRINTER SPEC - Memory | 256 MB RAM; 512 MB Flash (standard) |
| PRINTER SPEC - Maximum Print Width | ZQ610 Plus: 1.9 in. (48 mm) | ZQ620 Plus: 2.8 in. (72 mm) | ZQ630 Plus: 4.1 in. (104 mm) |
| PRINTER SPEC - Maximum Print Speed | Up to 4.5 in./sec (115 mm/sec) |
| PRINTER SPEC - Media Sensors | Black mark and gap media sensing using fixed center position sensors; label present sensor for issuing batch labels one at a time |
| PRINTER SPEC - Print Length Range | Minimum: 0.5 in. (12.7 mm) | Maximum: 32 in. (813 mm) |
| PRINTER SPEC - Power & Battery | ZQ610/ZQ620 Plus: 3250 mAh (23.4 Wh) removable, rechargeable PowerPrecision+ Li-Ion battery | ZQ630 Plus: 6600 mAh (47.5 Wh) removable PowerPrecision+ Li-Ion battery |
| MEDIA - Label & Liner Length | 0.5 in. (12.7 mm) to 32 in. (813 mm) or continuous |
| MEDIA - Media Width Range | ZQ610 Plus: 1.0–2.18 in. (25–55.4 mm) | ZQ620 Plus: 1.0–3.125 in. (25–79 mm) | ZQ630 Plus: 2.0–4.4 in. (51–112 mm linered) / 2.0–4.1 in. (51–104 mm linerless) |
| MEDIA - Maximum Media Roll Size | ZQ610 Plus: 2.2 in. (55.9 mm) OD | ZQ620 Plus & ZQ630 Plus: 2.6 in. (66 mm) OD (Inner core: 0.75 in. / 19 mm or 1.375 in. / 34.9 mm) |
| MEDIA - Media Thickness Range | 2.3 mil to 5.5 mil tag stock or 6.5 mil label stock |
| MEDIA - Media Types | Die-cut labels and tags, linerless labels, receipt paper, RFID (ZQ630 Plus RFID compatible), black bar and gap |
| OPERATING - Environmental Temperatures | Operating Temp.: -4°F to 122°F (-20°C to 50°C) | Storage/Transportation Temp.: -13°F to 149°F (-25°C to 65°C) |
| OPERATING - Environmental Humidity | Operating Humidity: 10% to 90% non-condensing | Storage Humidity: 10% to 90% non-condensing |
| OPERATING - Agency Approvals | Emissions: FCC Part 15 Subpart B, EN55022 Class-B, EN60950, EN55024, VCCI Class B | Susceptibility: EN55024, EN61000-4-2/3/4/5 | Safety: CE, TUV, CSA | ENERGY STAR™ certified |
| OPERATING - Security Features | FIPS support is available at no cost as a printer OS download |
