VIGI Solar System ControllerÂ
| Fitur | Spesifikasi |
| VIGI PS90 | |
| Battery | |
| Type | Lithium |
| Intelligent Auxiliary Heat | Yes |
| Battery Capacity | 93.6 Ah (Max), 31.2 Ah (Per Lithium Battery) |
| Voltage | 10.95 V |
| Max. Output Voltage | 12.6 V |
| Life | More than 500 cycles†|
| Dimension | 9.4 × 2.9 × 2.8 in (240 × 74 × 72 mm) (Per Lithium Battery) |
| Charging Condition | 0°C~45°C; -30°C~45°C (With intelligent auxiliary heating) |
| Discharging Condition | -20°C~60°C; -30°C~60°C (With intelligent auxiliary heating) |
| HARDWARE | |
| Interface | 1× Three-pin Female Connector For Connecting The Controller; 1× Three-pin Male Connector For Connecting The Modular Battery; 2× Four-pin Female Connectors For Connecting The Solar Panel; 1× 10/100 Mbps RJ45; 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A) |
| Indicator LED | Quantity: 6 (1× SYS Indicator, 1× LAN Indicator, 1× PV Indicator, 3× BAT Indicator); Color: Blue |
| SOFTWARE FEATURES | |
| Load Control | Yes |
| High and Low Temperature Protection | Yes |
| Overdischarge Protection | Yes |
| Power Consumption Statistics | Yes |
| Displays Real-time Load Status | Yes |
| Battery Level Display | Yes |
| Time Zone Selection | Yes |
| Schedule Saving | Yes |
| Firmware Remote Update | Yes |
| Remote Reboot | Yes |
| Local LAN Management | Yes |
| Intelligent Auxiliary Heating Control | -30°C~5°C |
| Account Management | Yes |
| Remote Reset | Yes |
| Remote Message Push | Yes |
| OTHERS | |
| Certification | CB, PSE (Battery); CE, FCC, VCCI, IC, IP66 |
| Package Content | VIGI PS90; Installation Guide; Waterproof Cable Attachments; Mounting Accessories; Extension Cable; Box Key |
| Box Dimensions (W x D x H) | 18.9 × 16.8 × 6.4 in (481 × 426 × 163 mm) |
| Weight | Product Weight: 16.5 kg; Package Weight: 24 kg |
| Environment | Operating Temperature: -30°C-60°C (With intelligent auxiliary heating); Operating Humidity: 10%~90%RH, Non-condensing |
