| Fitur | Spesifikasi |
| VIGI NVR4032H | |
| Video and Audio | |
| IP Video Input | 32-Channel |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 320 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Video Output Mode | HDMI/VGA Independent Output |
| Multi-View Display | 1/4/6/8/9/16/25/32/36 |
| DECODING | |
| Audio Compression | G.711A/G.711U/G.726 |
| Decoding Format | H.265+/H.265/H.264+/H.264 |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Live View/Playback Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-Channel |
| Capability | 16-ch @ 1080p (30 fps), 8-ch @ 4MP (30 fps), 4-ch @ 8MP (30 fps) |
| Record Management | |
| Record Mode | Manual Recording; Scheduling Recording; Motion Detection Recording |
| Playback Mode | Instant Playback; Regular Playback; Tag Playback; Event Playback |
| Backup Mode | Regular Backup; Video Clip Backup |
| Playback Function | Play; Pause; Stop; Fast Forward; Fast Backward; Play By Frame; Full Screen; Video Clip; Export Clip; Digital Zoom; Lock Recording; Audio On/Off |
| NETWORK | |
| Protocol | UPnP (Plug and Play), NTP (Network Timing), TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Incoming Bandwith | 320 Mbps |
| Outgoing Bandwidth | 320 Mbps |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF, CGI |
| External Interface | |
| Network Interface | 2, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | |
| Audio Interface | 1, Audio In; 1, Audio Out |
| Alarm In/Out | 16-Apr |
| Serial Interface | 1, RS232 |
| Power | 1× AC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | N/A |
| HDMI | 1 |
| VGA | 1 |
| HARD DISK | |
| SATA | 4 SATA Interfaces |
| Capacity | Up to 10 TB Capacity for Each HDD |
| Alarm | |
| General Alarm | Motion Detection; Video Tampering; Intrusion Detection; Line-Crossing Detection |
| Anomaly Alarm | Video Loss; Offline and IP Conflict; Disk Exception; Login Exception; Fan Exception |
| Alarm Linkage | Recording; White Light Alarm; Buzzer; Log; Audible Alarm |
| Network Management | |
| Network Protocols | UPnP (Plug and Play), NTP (Network Timing) |
| Interoperability | ONVIF, CGI |
| Mobile Phone Access | Android, iOS |
| Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Record Playback | |
| Record Mode | Manual Recording; Scheduling Recording; Motion Detection Recording |
| Playback Mode | Instant Playback; Regular Playback; Tag Playback; Event Playback |
| Backup Mode | Regular Backup; Video Clip Backup |
| Playback Function | Play; Pause; Stop; Fast Forward; Fast Backward; Play by Frame; Full Screen; Video Clip; Export Clip; Digital Zoom; Lock Recording; Audio On/Off |
| GENERAL | |
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Content | VIGI Network Video Recorder; Mouse; Installation Guide; Power Cord, HDD Power Cables, HDD Data Cables, and Terminal Blocks; Mounting Brackets, Screws and Rubber Feet |
| Working Temperature | -10–55 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions (W x D x H) | 440 × 330 × 44 mm |
| External Power Supply | 100-240 VAC, 50 to 60Hz, 1.5A |
| Net Weight | 4.0 Kg |
| Gross Weight | 5.2 Kg# |
| Power Supply | 100-240 VAC, 50 to 60Hz, 1.5A |
| Max. Power Consumption | 5 W (Without Disk); 48 W (With Disk) |
| Certifications | CE, EAC, UKCA, RCM, Triman, RoHS, VCCI, FCC, IC, HDMI |
| VIDEO/IMAGE | |
| IP Video Input | 32-Channel |
| Multi-View Display | 1/4/6/8/9/16/25/32/36 |
| Video Output Mode | HDMI/VGA Independent Output |
| Recording Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
