TP-LINK OMADA EAP115

Kategori :

Wall Mount AP
Tanyakan mengenai produk ini

Deskripsi

300Mbps Wireless N Wall-Plate Access Point

  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)‡, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • Elegant Appearance: Unprecedented thin design with just 11 mm, the same size and shape as a light switch or power outlet faceplate to fit perfectly in any room.
  • Easy Installation and PoE Support: Easy-mount construction, compatible with 86 mm & EU standard junction box, and 802.3af PoE support.
  • Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
SectionFeatureValue
HARDWARE FEATURESInterfaceUplink: 1× 10/100 Mbps Ethernet Port
Downlink: 1× 10/100 Mbps Ethernet Port
HARDWARE FEATURESPhysical Security LockNo
HARDWARE FEATURESButtonLED/Wi-Fi Button
RESET
HARDWARE FEATURESPower SupplyPoE (IEEE 802.3af)
HARDWARE FEATURESMax. Power Consumption2.8 W
HARDWARE FEATURESDimensions (W x D x H)3.4 × 3.4 × 1.2 in (86.8 × 86.8 × 30.2 mm)
HARDWARE FEATURESAntennaInternal 2× 1.8 dBi Omni
HARDWARE FEATURESMountingWall Plate Mounting
HARDWARE FEATURESHardware Watch DogYes
WIRELESS FEATURESCoverage25㎡(300 ft²)**
WIRELESS FEATURESConcurrent Clients100+*
WIRELESS FEATURESWireless StandardsIEEE 802.11n/g/b
WIRELESS FEATURESFrequency2.4 GHz
WIRELESS FEATURESSignal Rate11n: Up to 300 Mbps (dynamic)
11g: Up to 54 Mbps (dynamic)
11b: Up to 11 Mbps (dynamic)
WIRELESS FEATURESWireless FunctionsMultiple SSIDs (Up to 8 SSIDs)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
WIRELESS FEATURESWireless SecurityCaptive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Local LAN port based VLAN
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
WIRELESS FEATURESTransmission PowerCE: ≤20 dBm (2.4 GHz)
Management FeaturesOmada AppYes
Management FeaturesCentralized ManagementOmada Hardware Controller
Omada Software Controller
Management FeaturesCloud AccessYes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Management FeaturesEmail AlertsYes
Management FeaturesLED ON/OFF ControlYes
Management FeaturesManagement MAC Access ControlYes
Management FeaturesSNMPv1,v2c
Management FeaturesSystem Logging Local/Remote SyslogLocal/Remote Syslog
Management FeaturesSSHYes
Management FeaturesWeb-based ManagementHTTP/HTTPS
Management FeaturesL3 ManagementYes
Management FeaturesMulti-site ManagementYes
Management FeaturesManagement VLANYes
OTHERSCertificationCE, RoHS
OTHERSPackage Content300 Mbps Wireless N Wall-Plate Access Point EAP115-Wall
Installation Guide
Mounting Screw
OTHERSSystem RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10
OTHERSEnvironmentOperating Temperature: 0–40 ℃ (32–104 ℉)
Storage Temperature: -40–70 ℃ (-40–158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
