| Category | Parameter | Value | Unit/Notes |
| Hardware Features | Standards and Protocols | IEEE 802.3i, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x | |
| Hardware Features | Interface | 16× 10/100/1000 Mbps RJ45 Ports | Ports 1–8 Support 802.3at/af PoE+ |
| Hardware Features | Interface | Auto-Negotiation/Auto MDI/MDIX | |
| Hardware Features | Network Media | 10BASE-T: UTP category 3, 4, 5 cable | Maximum 100m |
| Hardware Features | Network Media | 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable | Maximum 100m |
| Hardware Features | Fan Quantity | Fanless | |
| Hardware Features | Power Supply | External Power Adapter | Output: 53.5 VDC / 2.43 A |
| Hardware Features | PoE Ports | 8 Ports | 802.3af/at compliant |
| Hardware Features | PoE Power Supply | 120 W | |
| Hardware Features | Dimensions (W x D x H) | 11.3 × 4.4 × 1.0 | in |
| Hardware Features | Dimensions (W x D x H) | 286 × 111.7 × 25.4 | mm |
| Hardware Features | Mounting | Desktop/Wall-Mounting | |
| Hardware Features | Max Power Consumption | 146.5 W | 110 V/60 Hz with 120 W PD connected |
| Hardware Features | Max Heat Dissipation | 499.98 BTU/hr | 110 V/60 Hz with 120 W PD connected |
| Performance | Bandwidth/Backplane | 16 Gbps | |
| Performance | MAC Address Table | 8k | |
| Performance | Packet Buffer Memory | 4.1 Mbit | |
| Performance | Jumbo Frame | 9 KB | |
| Software Features | Quality of Service | 802.1p CoS/DSCP priority | |
| Software Features | Priority Queues | 8 priority queues | |
| Software Features | Priority Schedule Mode | SP (Strict Priority), WRR (Weighted Round Robin) | |
| Software Features | Queue Weight Config | Yes | |
| Software Features | Bandwidth Control | Port/Flow-based Rating Limit | |
| Software Features | Storm Control | Broadcast/Multicast/Unknown-Unicast Control | Multiple Control Modes |
| Software Features | DHCP Relay | DHCP VLAN Relay, DHCP L2 Relay | |
| Software Features | Link Aggregation | Static Link Aggregation, 802.3ad LACP | Up to 8 groups |
| Software Features | Spanning Tree Protocol | 802.1D STP, 802.1w RSTP, 802.1s MSTP | |
| Software Features | Loopback Detection | Yes | |
| Software Features | Flow Control | 802.3x Flow Control | |
| Software Features | Mirroring | Port/CPU/Flow-Based Mirroring | Ingress/Egress/Both |
| Software Features | DLDP | Device Link Detect Protocol | |
| Software Features | LLDP | 802.1ab LLDP / LLDP-MED | |
| L2 Multicast | IPv4/IPv6 Shared Multicast Groups | 511 | |
| L2 Multicast | IGMP Snooping | v1/v2/v3 | |
| L2 Multicast | MLD Snooping | v1/v2 | |
| L2 Multicast | Multicast VLAN Registration | MVR | |
| L2 Multicast | Limited IP Multicast | 256 profiles and 16 entries per profile | |
| Advanced Features | Automatic Device Discovery | Yes | |
| Advanced Features | Batch Configuration | Yes | |
| Advanced Features | Batch Firmware Upgrading | Yes | |
| Advanced Features | Intelligent Network Monitoring | Yes | |
| Advanced Features | Abnormal Event Warnings | Yes | |
| Advanced Features | Unified Configuration | Yes | |
| Advanced Features | Reboot Schedule | Yes | |
| IPv6 Support | IPv6 Dual Stack | IPv4/IPv6 | |
| IPv6 Support | MLD Snooping | Supported | |
| IPv6 Support | IPv6 Applications | DHCPv6, Ping6, Tracert6, IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP | |
| VLAN | Max VLAN Groups | 4K | |
| VLAN | 802.1Q Tag VLAN | Supported | |
| VLAN | MAC VLAN | 12 Entries | |
| VLAN | Protocol VLAN | Supported | |
| VLAN | GVRP | Supported | |
| VLAN | Voice VLAN | Supported | |
| Access Control List | ACL Entries | Up to 230 entries | |
| Access Control List | ACL Types | MAC ACL, IP ACL, IPv6 ACL, Combined ACL | |
| Access Control List | Policy Actions | Mirror, Rate Limit, Redirect, QoS Remark | |
| Security | AAA | Supported | |
| Security | 802.1X | Port-based and MAC-based authentication | |
| Security | IP/IPv6-MAC Binding | 512 Binding Entries | |
| Security | IP Source Guard | 253 Entries | |
| Security | IPv6 Source Guard | 183 Entries | |
| Security | DoS Defend | Supported | |
| Security | Port Security | Up to 64 MAC addresses per port | |
| Security | HTTPS Management | SSLv3/TLS 1.2 | |
| Security | SSH Management | SSHv1/SSHv2 | |
| MIBs | Supported MIBs | RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757 | |
| Management | Omada App | Yes | Cloud-Based Controller / OC300 / OC200 / Software Controller |
| Management | Centralized Management | Supported | Omada Controllers |
| Management | Cloud Access | Yes | |
| Management | Zero-Touch Provisioning | Yes | Requires Omada Cloud-Based Controller |
| Management | Management Features | Web GUI, CLI, SNMP, RMON, DHCP Client, Dual Image, CPU Monitoring, Cable Diagnostics, SNTP, System Log | |
| Others | Certification | CE, FCC, RoHS | |
| Others | Package Contents | TL-SG2016P, Power Adapter, Installation Guide, Rubber Feet | |
| Others | System Requirements | Windows, MAC OS, NetWare, UNIX, Linux | |
| Environment | Operating Temperature | 0–40°C | 32–104°F |
| Environment | Storage Temperature | -40–70°C | -40–158°F |
| Environment | Operating Humidity | 10–90% RH | Non-condensing |
| Environment | Storage Humidity | 5–90% RH | Non-condensing |
