SG3452X

Kategori :

Managed Switch
Tanyakan mengenai produk ini

Deskripsi

Omada 48-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots

  • 4× 10 Gbps SFP+ slots enable high-bandwidth connectivity
  • 48× Gigabit RJ45 ports
  • 176 Gbps Switching Capacity
  • Centralized cloud management via the web or the Omada app†
  • Standalone management via web, CLI, SNMP, and RMON
  • Static Routing helps route internal traffic for higher efficiency
  • VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
  • ERPS supports rapid protection and recovery in a ring topology
  • Fanless design for silent operation
  • Durable metal casing and rackmountable design
FiturSpesifikasi
TP-Link TL-SG3452X
HARDWARE FEATURES
Interface48× 10/100/1000 Mbps RJ45 Ports; 4× 10G SFP+ Slots; 1× RJ45 Console Port; 1× Micro-USB Console Port
Fan QuantityFanless
Physical Security LockYes
Power Supply100–240 V AC, 50/60 Hz
Dimensions (W x D x H)17.3 × 8.7 × 1.7 in; 440 × 220 × 44 mm
MountingRack Mountable
Max. Power Consumption32.72 W (110 V/60 Hz)
Max. Heat Dissipation111.65 BTU/h (110 V/60 Hz)
PERFORMANCE
Switching Capacity176 Gbps
Packet Forwarding Rate130.9 Mpps
MAC Address Table16K
Packet Buffer Memory12 Mbit
Jumbo Frame9 KB
MANAGEMENT FEATURES
Omada AppYes; requires OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller
Centralized ManagementOmada Cloud-Based Controller; Omada Hardware Controller (OC300); Omada Hardware Controller (OC200); Omada Software Controller
Cloud AccessYes; requires OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller
Zero-Touch ProvisioningYes; requires Omada Cloud-Based Controller
Management FeaturesWeb-based GUI; Command Line Interface (CLI) through console port and telnet; SNMP v1/v2c/v3; Trap/Inform; RMON (1, 2, 3, 9 groups); SDM Template; DHCP/BOOTP Client; 802.1ab LLDP/LLDP-MED; DHCP AutoInstall; Dual Image, Dual Configuration; CPU Monitoring; Cable Diagnostics; EEE; Password Recovery; SNTP; System Log
OTHERS
CertificationCE, FCC, RoHS
Package ContentTL-SG3452X Switch; Power Cord; Quick Installation Guide; Rackmount Kit; Rubber Feet
System RequirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11; MAC® OS; NetWare®; UNIX® or Linux
EnvironmentOperating Temperature: 0–45 ℃ (32–113 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉); Operating Humidity: 10–90% RH non-condensing; Storage Humidity: 5–90% RH non-condensing
