Portable two-way radioÂ
A next-level workhorse, the MOTOTRBO R2 marries durability and ergonomics to ensure confident, easy handling. And with superior range, configurable audio and seamless integration, the R2 is a reliable addition to an uninterrupted workday.Â
Complementing its durability and ergonomics, the MOTOTRBO R2’s configurable audio ensures clear communication–helping you manage your day-to-day operations without skipping a beat.Â
Key FeaturesÂ
Sleek and ToughÂ
Durable, lightweight and long-lasting, MOTOTRBO R2 proves the right choice for all-day reliability, even in challenging work environments. Use with confidence in dusty factories, wet landscaping and more; and with ease, even while wearing gloves.Â
Make it LoudÂ
With SINC+ noise cancellation, long range and selectable audio profiles, MOTOTRBO R2 shines in noisy work environments; communicate with clarity to stay safe near a punch press, pneumatic drill, bulldozer and more.Â
Work, UninterruptedÂ
MOTOTRBO R2 is the ultimate workhorse. Engineered to minimize downtime with a simplified user experience, foolproof ergonomics and low-cost migration, the R2 helps you manage your day to day operations without skipping a beat.Â
| Fitur | Spesifikasi |
| Motorola R2 | |
| GENERAL | |
| Frequency | VHF 136–174 MHz; UHF 400–480 MHz |
| Typical RF Output - High Power | 5 W (VHF); 4 W (UHF) |
| Typical RF Output - Low Power | 1 W |
| Channel Spacing | 12.5 / 25.0 kHz1 |
| Channel Capacity | 64 |
| Power Supply | 7.5 V (nominal) |
| FCC Description | AZ489FT3852; AZ489FT4971 |
| IC Description | 89FT3852; 109U-89FT4971 |
| MOTOTRBO R2 with Slim IP55 2100 mAh Battery (PMNN4600) | |
| Dimension (H x W x D) | 4.9 x 2.2 x 1.3 in. |
| Weight | 9.2 oz |
| Battery Life (Analog / Digital) | 17 Hours / 22.5 Hours |
| MOTOTRBO R2 with High Capacity IP55 2300 mAh Battery (PMNN4598) | |
| Dimension (H x W x D) | 4.9 x 2.2 x 1.5 in. |
| Weight | 10.1 oz |
| Battery Life (Analog / Digital) | 19.5 Hours / 26.5 Hours |
| TRANSMITTER | |
| 4FSK Digital Modulation | 12.5 kHz Data: 7K60F1D and 7K60FXD; 12.5 kHz Voice: 7K60F1E and 7K60FXE; Combination: 7K60F1W |
| Digital Protocol | ETSI TS 102 361-1, -2, -3 DMR Tier II |
| Conducted/Radiated Spurious Emissions | < -36 dBm for < 1 GHz; < -30 dBm for > 1 GHz |
| Adjacent Channel Power | > 60 dB @ 12.5 kHz; > 70 dB @ 25 kHz |
| Frequency Stability | ± 0.5 ppm |
| Modulation Limiting | ± 2.5 kHz @ 12.5 kHz; ± 5.0 kHz @ 25 kHz |
| RECEIVER | |
| Analog Sensitivity (12dB SINAD) | 0.18 μV (typical) |
| Digital Sensitivity (5% BER) | 0.16 μV (typical) |
| Conducted/Radiated Spurious Emissions | < -57 dBm for < 1 GHz; < -47 dBm for > 1 GHz |
| Intermodulation (TIA603E) | > 70 dB |
| Adjacent Channel Selectivity (TIA603A)-1T | > 60 dB @ 12.5 kHz; > 70 dB @ 25 kHz |
| Adjacent Channel Selectivity (TIA603E)-2T | > 55 dB @ 12.5 kHz; > 70 dB @ 25 kHz |
| Spurious Rejection (TIA603E) | > 70 dB |
| Frequency Stability | ± 0.5 ppm |
| AUDIO SPECIFICATIONS | |
| Digital Vocoder Type | AMBE+2 |
| Audio Response | +1, -3 dB |
| Audio Output Power (Rated / Max) | 1 W / 3 W |
| Audio Distortion at Rated Audio | 3% (typical) |
| Maximum Speech Loudness (ISO 532B) | 101 phons |
| Hum and Noise | -40 dB @ 12.5 kHz; -45 dB @ 25 kHz |
| ENVIRONMENTAL SPECIFICATIONS | |
| Operating Temperature | -30°C to 60°C (-22°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Thermal Shock | Per MIL-STD 810C, D, E, F, G, H |
| Humidity | Per MIL-STD 810C, D, E, F, G, H |
| Electrostatic Discharge | IEC 61000-4-2 Level 4 |
| Dust and Water Intrusion | IEC60529 IP55 |
| Salt Fog | Per MIL-STD 810C/D/E/F/G/H |
| Packaging Test | Per MIL-STD 810C/D/E/F/G/H |
