10/100Mbps WDM Media ConverterÂ
| Parameter / Feature | Specification Details |
| MEDIA CONVERTER - Standards & Protocols | IEEE 802.3i, IEEE 802.3u |
| MEDIA CONVERTER - Basic Functions | Adopts WDM technology | Half/Full-Duplex transfer mode for FX port | Extends fiber distance up to 20km |
| MEDIA CONVERTER - Interface Ports | 1× 100M SC/UPC port | 1× 10/100M RJ45 port (Auto MDI/MDIX) |
| MEDIA CONVERTER - Wave Length | 1550nm Tx / 1310nm Rx (WDM TX: 1550nm, WDM RX: 1310nm) |
| MEDIA CONVERTER - Network Media (10BASE-T) | UTP category 3, 4, 5 cable (Max 100m) / EIA/TIA-568 100Ω STP (Max 100m) |
| MEDIA CONVERTER - Network Media (100BASE-T) | UTP category 5, 5e cable (Max 100m) / EIA/TIA-568 100Ω STP (Max 100m) |
| MEDIA CONVERTER - Network Media (100BASE-FX) | Single-mode Fiber |
| HARDWARE - Dimensions (W x D x H) | 3.7 × 2.9 × 1.1 in. (94.5 × 73.0 × 27.0 mm) |
| HARDWARE - Power Specs | External Power Adapter | Max Power Consumption: 1.23W |
| HARDWARE - LED Indicators | PWR, Link/Act |
| OTHERS - Safety & Emission Certifications | FCC, CE, RoHS |
| OTHERS - Package Contents | Media Converter MC111CS | Power Adapter | Installation Guide |
| OTHERS - Environmental Conditions | Operating Temp: 0℃~40℃ (32℉~104℉) | Storage Temp: -40℃~70℃ (-40℉~158℉) | Operating Humidity: 10%~90% non-condensing | Storage Humidity: 5%~90% non-condensing |
