ER7206

Kategori :

Omada Gateaway VPN Router
Tanyakan mengenai produk ini

Deskripsi

Omada Gigabit VPN Gateway

  • 1× Gigabit SFP WAN/LAN port
  • 5× Gigabit RJ45 ports (1× WAN, 4× WAN/LAN)
  • 1× USB 3.0 port (Supports USB storage, and LTE backup with LTE dongle)
  • Load Balancing on up to 5 WAN ports raises the utilization rate of multi-line broadband
  • High-security SSL/ IPSec / GRE§ / WireGuard / PPTP / L2TP VPN & OpenVPN
  • Centralized cloud management via the web or the Omada app*
  • DoS/DDoS Protection, IP/MAC/Location/URL filtering, DPI, and IPS/IDS for enhanced security.
  • Rack Mount/Desktop/Wall Mount
FeatureSpecification
Access ControlSource/Destination IP Based Access Control
FilteringWEB Group Filtering§; URL Filtering; Web Security§
ARP InspectionSending GARP Packets§; ARP Scanning§; IP-MAC Binding
Attack DefenseTCP/UDP/ICMP Flood Defense; Block TCP Scan (Stealth FIN/Xmas/Null); Block Ping from WAN
WAN Connection TypeStatic IP; Dynamic IP; PPPoE (supports MRU Configuration); PPTP; L2TP
MAC CloneModify WAN/LAN MAC Address†
DHCPDHCP Server; DHCPv6 PD Server (only in Standalone Mode); DHCP Options Customization; DHCP Address Reservation; Multi-IP Interfaces; Multi-Net DHCP
IPv6StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode
VLAN802.1Q VLAN
IPTVIGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Omada AppYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized ManagementOmada Cloud-Based Controller; Omada Hardware Controller; Omada Software Controller
Cloud AccessYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
MaintenanceWeb Management Interface; Remote Management; Export & Import Configuration; SNMP v1/v2c/v3; Diagnostics (Ping & Traceroute)§; NTP Synchronize§; Port Mirroring; CLI (only in Standalone Mode); Syslog Support
Zero-Touch ProvisioningYes. Requires the use of Omada Cloud-Based Controller.
Management FeaturesAutomatic Device Discovery*; Batch Configuration*; Batch Firmware Upgrading*; Intelligent Network Monitoring*; Abnormal Event Warnings*; Unified Configuration*; Reboot Schedule*
CertificationCE, FCC, RoHS
Package ContentER7206; Power Adapter; Quick Installation Guide; Rackmount Kit
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10; MAC OS, NetWare, UNIX or Linux
EnvironmentOperating Temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F); Operating Humidity: 10% to 90% non-condensing; Storage Humidity: 5% to 90% non-condensing
