EAP620 HD

Kategori :

Ceiling Mount AP
Tanyakan mengenai produk ini

Deskripsi

AX1800 Wireless Dual Band Ceiling Mount Access Point

  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.
  • High-Density Connectivity: 4× increased capacity to connect more devices simultaneously.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralised Management: Cloud access and Omada app for ultra convenience and easy management.
  • Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.
  • PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation.
  • Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
FeatureSpecification
HARDWARE FEATURES - Interface1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE and Passive PoE)
HARDWARE FEATURES - ButtonReset
HARDWARE FEATURES - Power Supply48V Passive PoE or 802.3at PoE or 12V/1.5A DC
HARDWARE FEATURES - Max. Power ConsumptionEU: 14.4 W (For PoE); 13.1 W (for DC); US: 14.9 W (For PoE); 13.4 W (for DC)
HARDWARE FEATURES - Dimensions (W x D x H)6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
HARDWARE FEATURES - AntennaInternal Omni Antenna; 2.4 GHz: 2× 4 dBi; 5 GHz: 2× 5 dBi
HARDWARE FEATURES - MountingCeiling / Wall Mounting (Kits included); Junction Box Mounting
WIRELESS FEATURES - Coverage140㎡ (1500 ft²) ***
WIRELESS FEATURES - Concurrent Clients1,020+ **
WIRELESS FEATURES - Wireless StandardsIEEE 802.11ax/ac/n/g/b/a
WIRELESS FEATURES - Frequency2.4 GHz and 5 GHz
WIRELESS FEATURES - Signal Rate5 GHz: Up to 1201 Mbps †; 2.4 GHz: Up to 574 Mbps †
WIRELESS FEATURES - Wireless Functions1024-QAM; 4× Longer OFDM Symbol; OFDMA; Multiple SSIDs (Up to 16 SSIDs, 8 for each band); Enable/Disable Wireless Radio; Automatic Channel Assignment; Transmit Power Control (Adjust Transmit Power on dBm); QoS (WMM); MU-MIMO; Seamless Roaming △; Omada Mesh △; Band Steering; Load Balance; Airtime Fairness; Beamforming; Rate Limit; Reboot Schedule; Wireless Schedule; Wireless Statistics based on SSID/AP/Client
WIRELESS FEATURES - Wireless SecurityCaptive Portal Authentication â–³; Access Control; Wireless Mac Address Filtering; Wireless Isolation Between Clients; SSID to VLAN Mapping; Rogue AP Detection; 802.1X Support; WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
WIRELESS FEATURES - Transmission PowerCE: <20 dBm (2.4 GHz, EIRP); <23 dBm (5 GHz band1/2, EIRP); <25 dBm (5 GHz band3); FCC: <25 dBm (2.4 GHz); <25 dBm (5 GHz)
MANAGEMENT FEATURES - Omada AppYes
MANAGEMENT FEATURES - Centralized ManagementOmada Cloud-Based Controller (Supported by EAP620 HD v2.0 and above); Omada Hardware Controller OC300; Omada Hardware Controller OC200; Omada Software Controller
MANAGEMENT FEATURES - Cloud AccessYes, through OC300; OC200; Omada Software Controller; Omada Cloud-Based Controller (Supported by EAP620 HD v2.0 and above)
MANAGEMENT FEATURES - Email AlertsYes
MANAGEMENT FEATURES - LED ON/OFF ControlYes
MANAGEMENT FEATURES - Management MAC Access ControlYes
MANAGEMENT FEATURES - SNMPv1, v2c, v3
MANAGEMENT FEATURES - System Logging Local/Remote SyslogLocal/Remote Syslog
MANAGEMENT FEATURES - SSHYes
MANAGEMENT FEATURES - Web-based ManagementHTTP/HTTPS
MANAGEMENT FEATURES - L3 ManagementYes
MANAGEMENT FEATURES - Multi-site ManagementYes
MANAGEMENT FEATURES - Management VLANYes
MANAGEMENT FEATURES - Zero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller (Supported by EAP620 HD v2.0 and above)
OTHERS - CertificationCE, FCC, RoHS
OTHERS - Package ContentEAP620 HD; Power Adapter; Ceiling / Wall Mounting Kits; Installation Guide
OTHERS - System RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
OTHERS - EnvironmentOperating Temperature: 0–40 ℃ (32–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉); Operating Humidity: 10–90% RH non-condensing; Storage Humidity: 5–90% RH non-condensing
