Hybrid Handheld/hands-free scannerÂ
The ultimate in performance and design. Handheld and hands-free use, the DS9908 delivers optimum performance, whether associates pass items quickly in front of the scanner or pick it up to scan merchandise on the counter or in a cart.Â
In the BoxÂ
Key FeaturesÂ
Commonly Used ForÂ
| Feature | Specification |
| Dimensions | DS9908: 8.0 in H x 3.7 in W x 5.2 in D (20.3 x 9.4 x 13.2 cm); DS9908R: 8.0 in H x 3.9 in W x 5.75 in D (20.3 x 9.9 x 14.6 cm) |
| Weight | DS9908: 11.6 oz / 330 g; DS9908R: 14.8 oz / 420 g |
| Input Voltage Range | 4.5–5.5 VDC host powered/external |
| Current | DS9908 operating 321 mA; DS9908R 400 mA; standby 70 mA / 135 mA |
| Color | Midnight Black |
| Supported Host Interfaces | USB; RS232; Keyboard Wedge; TGCS IBM 46XX over RS485 |
| Keyboard Support | 90+ international keyboards |
| EAS | Checkpoint EAS compatible |
| TAA Compliance | Yes |
| User Indicators | Decode indicator; LEDs; speaker adjustable |
| Swipe Speed | Up to 240 in/s (610 cm/s) |
| Light Source | 617nm amber LED aiming pattern |
| Illumination | 2x 645nm red LEDs |
| Imager Field of View | 48° x 30.6° |
| Image Sensor | 1280 x 800 |
| Minimum Print Contrast | 16% |
| Skew/Pitch | ±60° / ±60° |
| Roll Tolerance | 0–360° |
| 1D Symbologies | Code 39, Code 128, Code 93, Codabar, Code 11, MSI, UPC/EAN, I 2 of 5, GS1 DataBar |
| 2D Symbologies | PDF417, MicroPDF417, Aztec, DataMatrix, QR, Micro QR, MaxiCode |
| OCR | OCR-A, OCR-B, MICR, US Currency |
| Digimarc | Supported |
| Resolution | Code39 3.0 mil; Code128 3.0 mil; DataMatrix 6.0 mil; QR 6.0 mil |
| Warranty | 5 years |
| Operating Temperature | 0–50 °C |
| Storage Temperature | -40–70 °C |
| Humidity | 5–95% RH non-condensing |
| Drop | 5 ft DS9908; 4 ft DS9908R |
| Tumble | 2000 tumbles |
| Sealing | IP52 DS9908; IP42 DS9908R |
| ESD | ±15kV air; ±8kV contact/indirect |
| Ambient Light | 0–10,000 foot candles |
