hands-free scannerÂ
Purpose-built for medical labs and pharmacies, the DS9900 Series Hybrid Presentation Imager improves workflow efficiency and accuracy. Workers get first-time, every time capture of the many types of barcodes found in the lab, including small, high density, curved, and colour-coded.Â
In the BoxÂ
Key FeaturesÂ
Commonly Used ForÂ
| Feature | Specification |
| Dimensions | DS9908: 8.0 in H x 3.7 in W x 5.2 in D (20.3 x 9.4 x 13.2 cm); DS9908R: 8.0 in H x 3.9 in W x 5.75 in D (20.3 x 9.9 x 14.6 cm) |
| Weight | DS9908: 11.6 oz / 330 g; DS9908R: 14.8 oz / 420 g |
| Input Voltage Range | 4.5–5.5 VDC host/external power |
| Current | DS9908 operating 321 mA; DS9908R 400 mA; standby 70 mA / 135 mA |
| Color | Midnight Black |
| Supported Host Interfaces | USB Certified; RS232; Keyboard Wedge; TGCS IBM 46XX over RS485 |
| Keyboard Support | 90+ international keyboards |
| EAS | Checkpoint EAS compatible |
| TAA Compliance | Trade Agreement Act compliant |
| User Indicators | Decode indicator; LEDs; speaker adjustable tone/volume |
| Performance | Swipe up to 240 in/s; 48° x 30.6° field of view; 1280x800 sensor |
| Optics | 617nm amber aiming LED; 645nm red illumination |
| Decode Capability 1D | Code 39, Code 128, Code 93, Codabar, Code 11, MSI, UPC/EAN, I 2 of 5, GS1 DataBar |
| Decode Capability 2D | PDF417, Micro PDF417, Aztec, DataMatrix, QR, Micro QR, MaxiCode, Han Xin |
| OCR | OCR-A, OCR-B, MICR, US Currency |
| Digimarc | Supported |
| Resolution | Code39 3.0 mil; Code128 3.0 mil; DataMatrix 6.0 mil; QR 6.0 mil |
| Warranty | 5 years |
| Operating Temperature | 0–50 °C |
| Storage Temperature | -40–70 °C |
| Humidity | 5–95% RH non-condensing |
| Drop Specification | DS9908 5 ft; DS9908R 4 ft |
| Tumble | 2000 tumbles |
| Sealing | IP52 DS9908; IP42 DS9908R |
| ESD | ±15 kV air; ±8 kV direct/indirect |
| Ambient Light | 0–10,000 foot candles |
| Accessories | Multi-mount bracket |
| Utilities | 123Scan; SDK; SMS |
| Imaging Output | Bitmap; JPEG; TIFF |
| Image Quality | 116 PPI A4 @ 8 in |
